glass to metal seal,  6 copper cored Alloy 50 leads, #10 CRS housing,  Au finishing on the leads.

  Housing   Cap Leads  Insulators
Materials   CRS#10 Kovar Copper cored 4J50 Elan#13
Plating  Ni: 3~8.9μm  Ni: 3~8.9μm, Au≥1.3μm
Dimensions   Base L:11.5mm+0.2  W:10.5+0.2 , Cap H:7.45mm
Insulation resistance   ≥1× 1010 Ω (500V DC)
Hermeticity   ≤  1 x 10-3  Pa * cm/s
Note Unspecified tolerances are ±0.2mm

With over two decades of experience helping clients move from prototype to commercialization, Hermetica’s customized engineering service offers immense value at the R&D stage. From material selection to pin configuration to sealing techniques, our team of engineers can provide a variety of solutions to help you overcome the technical obstacles our clients face in the early phases of designing a new product. We can work from your drawings or ours while pinpointing ways to lower costs and improve functionality.
